Star TSP654LAN Receipt Printer and Cash Drawer Hardware Bundle Square PayPal Here
• Free UPS Ground Shipping to Continental USA
• Star TSP654LAN Ethernet Receipt Printer and a NEW Compatible Cash Drawer
• Compatible with Square Register, PayPal Here and many other POS apps
• New Standard Duty, Reliable Cash Drawer with Lock
• Printer connects to wifi router via wired ethernet port, cash drawer plugs into printer
• Receipt Autocutter Installed, Power Supply and Cord Included
• Dark Gray Color Printer, Black Cash Drawer with 5 Space Till
• All Cables, Receipt Paper Roll and Everything you need to get started is included
• Tablet or Square Stand Hardware is NOT included
Cash Drawer Specifications :
| Dimensions | 16.5" x 16" x 3.5" |
| Weight | 12 lbs |
| Color | Black |
| Lock | 3 Position Lock & 2 keys included |
| Cables | Rj11 Cash Drawer Kick Cable Included |
| Till | 5 space bill and 5 space coin trays |
| Material | Metal bottom case, plastic till with removable trays |
Star TSP654LAN Specifications :
|
Printer Method |
Direct Line Thermal |
|
Print Speed |
30 Receipts Per Minute (150 mm/sec) |
|
Printer Case Color |
Putty or Gray |
|
Models Available |
Tear Bar or Auto Cutter |
|
Print Resolution |
203 dpi |
|
No. of Columns |
48 / 64 |
|
Font Size |
9 x 24 |
|
Character Set |
ANK 95, 32 Int 128 Graphic |
|
International Code Pages |
Star Mode=40. ESC/POS™= 6 + 1 blank allowing an additional character page to be added |
|
Bar Codes |
9 versions / PDF 417 Option |
|
Line Spacing |
3 mm or 4 mm or programmable |
|
Paper Specifications |
|
|
Top Margin |
11 mm or 13 mm minimum default |
|
Auto Cutter |
Guillotine (Partial Cut Only) |
|
Cover Open Sensor |
Yes |
|
Logo Store Capacity |
2 Mbit Flash ROM with Graphic Management Software |
|
Flash ROM |
16 Mbit |
|
Multiple Copy Support |
Available through Star Raster Driver |
|
Journal Capability |
N/A |
|
Label Support |
N/A |
|
Power Supply |
External; Requires PS60A External Power Supply |
|
Drivers Available |
Windows® XP 32 Bit, Vista 32/64 Bit, Windows 7 32/64 Bit, Server 2008 32/64 Bit, XP Embedded, CE, POSReady 2009, OPOS™, JavaPOS™, USB Vendor Class, Linux™, Mac OS X, StarIO SDK with support for iOS, Android and Blackberry |
|
Digitally Signed (WHQL) |
N/A |
|
Swappable Interfaces |
Yes |
|
Connectivity Options |
Serial, Parallel, USB, or Ethernet |
|
Emulation Modes |
Star Mode, ESC/POS™ |
|
Peripheral Drive Circuit |
2 circuits, (24V max. 1A), 1 Compulsion input |
|
Power Consumption |
Average 1.8 Amp. Printing, 0.15 Amp. Standby |
|
Operating Conditions |
Temperature: 5ºC to 45ºC |
|
Storage Conditions |
Temperature: -20ºC to 60ºC |
|
Dimensions |
142 x 132 x 202 (w x h x d)mm |
|
Safety Standards |
UL, C-UL, TüV, FCC, VCCI, EN55022, CE, Gost |
|
Reliability MCBF |
60 Million Lines |
|
Options |
External Power Supply (PS60A) |
